Specifications

Engine and Performance:

• Engine Type: Fan-cooled, 4-stroke, SI engine

• Displacement: 109.51 cc

• Maximum Power: 7.73 horsepower at 8000 rpm

• Maximum Torque: 8.90 Nm at 5500 rpm

• Fuel System: Programmed Fuel Injection (PGM-FI)

• Starting System: Kick and Electric Start

• Transmission: Automatic (CVT)

Dimensions and Weight:

• Length: 1833 mm

• Width: 697 mm

• Height: 1156 mm

• Wheelbase: 1260 mm

• Ground Clearance: 171 mm

• Seat Height: 765 mm

• Kerb Weight: 106 kg

Fuel Capacity:

• Fuel Tank Capacity: 5.3 liters

Brakes and Suspension:

• Front Brake: Drum (130 mm)

• Rear Brake: Drum (130 mm)

• Braking System: Combi-Brake System (CBS) with Equalizer

• Front Suspension: Telescopic

• Rear Suspension: 3-step adjustable spring-loaded hydraulic

Tyres and Wheels:

• Tyre Type: Tubeless

• Front Tyre: 90/90 – 12

• Rear Tyre: 90/100 – 10

Features:

• Digital Analog Meter Console (DLX specific)

• Enhanced Smart Power (eSP) Technology

• Silent Start with ACG Motor

• Engine Start/Stop Switch

• External Fuel Lid

• LED Headlamp and Position Lamp

• Retractable Rear Hook

• Stylish Tail Lamp Design
