Specifications

Engine and Performance

• Engine type: 4-stroke, single-cylinder, air-cooled, BS6-compliant

• Displacement: 184.4 cc

• Maximum power: 17.27 PS at 8500 rpm

• Maximum torque: 15.9 Nm at 6000 rpm

• Bore x Stroke: 61.0 mm x 63.09 mm

• Compression ratio: 9.5:1

• Fuel system: Programmed fuel injection (PGM-FI)

• Starting system: Self-start only

• Transmission: 5-speed manual

• Clutch: Multiplate wet clutch

Chassis and Suspension

• Frame type: Diamond-type frame

• Front suspension: Upside Down (USD) telescopic forks

• Rear suspension: Monoshock with preload adjuster

Brakes and Tyres

• Front brake: 276 mm disc

• Rear brake: 220 mm disc

• ABS: Single-channel ABS

• Front tyre: 110/70-17 (tubeless)

• Rear tyre: 140/70-17 (tubeless)

• Wheels: Alloy

Dimensions and Weight

• Overall length: 2047 mm

• Width: 783 mm

• Height: 1064 mm

• Wheelbase: 1355 mm

• Ground clearance: 167 mm

• Seat height: 790 mm

• Kerb weight: 142 kg

• Fuel tank capacity: 12 liters

Electricals and Features

• Headlamp: LED

• Tail lamp: LED

• Turn indicators: LED

• Instrument cluster: Fully digital LCD with gear position indicator, trip meter, battery voltage, clock, and service reminder

• Battery: 12V, maintenance-free

• Engine kill switch: Yes

• Hazard light switch: Yes

Performance Figures (Approximate)

• Top speed: 130 kmph

• Mileage: 40 to 45 kmpl
